제품 사양
Sample Port Diameter
9.5 mm
Spectral Range
250 ~ 2500 nm
Sphere Coating
Spectralon
Sphere Diameter
38.1 mm
Dimensions
56.8 x 62.4 x 38.1 mm (LWH)
Side Mounts
(1) SMA 905 connector for coupling optical fiber to the spectrometer (1) 8-32 threaded hole for post mounts
Top Cap Mounts
(2) 8-32 (hardware not included) (1) ¼-20 threaded hole in center (screw/adapter included)
LED Adapter
NA
PTFE Reflectivity
NA
Weight
240 g
제품 설명

360° 시야각의 광장 수집 및 측정

LED, 레이저 등 방사 광원을 수집하여, 360° 시야각의 광장(light field)을 측정하는 데 사용됩니다.
